Discover the LIBRA4 AI Quad-Sensor UAV Camera featuring 48MP visible light camera, 640×512 thermal imaging, 22x lossless zoom, 1200m laser rangefinder, AI target tracking, and 6 TOPS onboard computing. Ideal for drone surveillance, inspection, and tactical operations.
The LIBRA4 Quadra-Sensor Gimbal Camera is a lightweight, high-performance drone payload system designed for UAV surveillance, reconnaissance, inspection, and tactical operations. Featuring dual visible light cameras, a thermal infrared sensor, and a laser rangefinder, it provides full-spectrum situational awareness. Onboard AI computing (6 TOPS) enables real-time target tracking, object recognition, and mission-specific automation. With a compact weight of 300g, the LIBRA4 is suitable for medium-sized drones with a 50cm wheelbase.
| Feature | Specification |
|---|---|
| Visible Camera | 48MP Sony CMOS, 11x optical, 22x lossless zoom |
| Thermal Camera | 640×512 sensor, 13mm aperture |
| Laser Rangefinder | 1200m range |
| AI Computing | 6 TOPS |
| Gimbal Yaw Range | ±150° |
| Roll Range | -85°~+85° |
| Pitch Range | -135°~+45° |
| Weight | 300g ±10g |
| Operating Voltage | 12V-24V |
| Temperature Range | -20~55°C |
| Storage | 128GB |
| Protection Rating | IP44 |
| Video Resolution | 4000×3000 @ 30fps |
| Photo Resolution | 12M / 24M / 48M |
Monitor borders, critical infrastructure, and urban areas with high-definition visual and thermal imaging.
Locate missing persons or detect heat sources in low visibility or night conditions using the thermal sensor.
Inspect power lines, pipelines, rooftops, and solar farms with precise laser rangefinding and high-resolution imagery.
Support law enforcement, counter-terrorism, and military operations with AI target tracking and split-screen sensor monitoring.
Track wildlife, assess environmental hazards, or conduct aerial research using combined EO/IR and thermal imaging.
Q1: What drones are compatible with LIBRA4?
A1: LIBRA4 is suitable for drones with a wheelbase around 50cm and payload capacity over 300g.
Q2: What is the maximum zoom and resolution of the camera?
A2: 11x optical zoom, 22x lossless zoom, and up to 48MP resolution for photos. Video resolution reaches 4000×3000 at 30fps.
Q3: Does LIBRA4 support thermal imaging?
A3: Yes, it has a 640×512 thermal sensor capable of detecting heat sources in day/night operations.
Q4: How far can the laser rangefinder measure?
A4: Up to 1200 meters for precise target positioning.
Q5: Can the camera perform AI-based tracking?
A5: Yes, onboard 6 TOPS computing enables real-time AI target recognition and tracking.
Q6: Is the LIBRA4 suitable for outdoor conditions?
A6: Yes, it operates in -20°C to +55°C and has IP44 protection.
Q7: How much does the LIBRA4 weigh?
A7: Approximately 300g ±10g, making it compatible with medium-sized UAVs.
Q8: What storage options are available?
A8: 128GB onboard memory for image and video storage.
