China Xinxing Xiamen has launched the CXXMZTT Armoured Ambulance, field sanitary technology vehicle,high performance.
|
Engine |
|
|
Model |
CUMMINS ISDE180 - 30 |
|
Max. power |
132KW 180HP |
|
Type |
Electric injection, turbocharged, intercooled diesel, Bosch common rail system |
|
Fuel |
Diesel |
|
Displacement |
4.5 L |
|
Size |
|
|
Outside size (L/W/H) |
5360mm/2320mm/2300mm |
|
Interior volume |
8 m³ |
|
Wheelbase |
3310mm |
|
Front tread/Rear tread |
1780mm/1780mm |
|
Min. Ground clearance |
300mm |
|
Tire size |
37×12.5R16.5 |
|
Weight |
|
|
GVW |
6500kg |
|
Complete vehicle curb mass |
5300kg |
|
Loading mass |
1200kg |
|
Performance |
|
|
Max. speed |
105km/h |
|
Max. torque |
650/1200 - 1700 N M |
|
Biggest continue voyage course |
600km |
|
Fuel tank capacity |
120L |
|
Passenger |
2 + 2 |
|
Max. gradeability |
60% |
|
Max. Fording depth |
800mm |
|
Barrier property |
|
|
Front, side and back |
It can withstand the type 53 7.62mm standard bullet at a distance of 100 meters |
