Crusader 70D remote demolition robot – 105kg attachment capacity, 7.5kW hydraulic power, 100m wireless digital control, load-sensing axial piston pump (19MPa, 27L/min). For concrete breaking, building dismantling, and industrial demolition.
Model: YGR70D
Power: 7.5 kW
Weight: 750 kg
Max speed: 2.7 km/h
Max gradeability: 30°
Control: wireless remote (100 m range)
Hydraulic system pressure: 19 MPa
Hydraulic pump: load-sensing axial piston variable pump
Hydraulic flow: 0–27 L/min
Hydraulic tank capacity: 27 L
Recommended attachment weight: 105 kg
Swing speed: 6 sec/250°
Start method: direct start
Motor type: YE3-132M-B5
Signal type: digital
Crusader 70D – Named for the Task – Named to crush concrete. Name to break reinforced structures. Named to dismantle what others cannot.
105kg – Bring the Big Breaker – Hydraulic hammers, crushers, pulverizers, shears. Whatever the job demands.
7.5kW of Hydraulic Muscle – Not a toy. Not a maintenance tool. Industrial demolition power.
19MPa – 2,755 PSI of Breaking Force – Pressure that cracks concrete. Force that cuts rebar.
Load-Sensing Axial Piston Pump – 0-27 L/min variable flow. Power on demand. No wasted energy.
100 Meters of Safe Distance – Wireless digital control. Keep your crew out of the collapse zone.
750kg of Stability – Heavy enough for big breakers. Light enough for standard trailers.
30° – Climb the Rubble – Debris piles. Slopes. Uneven demolition sites. Go where the work is.
27L Hydraulic Tank – Extended run time. Less downtime. More breaking.
Digital Signal Precision – Interference resistant. Instant response. Total control.
Ideal for (Version 2):
✔ Concrete building demolition and dismantling
✔ Bridge deck and pillar removal
✔ Industrial plant decommissioning
✔ Foundation and slab breaking
✔ Tunnel and underground demolition
✔ Reinforced concrete cutting
✔ Selective building dismantling
Q1: Why is it called Crusader 70D?
A: Crusader for its mission – to crush concrete and demolish structures. 70 for the 7.5kW power class (rounded to 70). D for dismantling.
Q2: How much breaker can it carry?
A: 105kg recommended attachment weight – full-size hydraulic breakers for real demolition work.
Q3: How many PSI is 19 MPa?
A: Approximately 2,755 PSI – enough hydraulic force for reinforced concrete breaking.
Q4: What is load-sensing hydraulics?
A: The pump delivers only the flow needed for the task. Power on demand. Less fuel/electricity. Less heat.
Q5: How far away can I control it?
A: 100 meters wireless digital control – keep your operator safe from the collapse zone.
